200 ton J23 c press mechanical punching machine

Rumah / Produk / 200 ton J23 c press mechanical punching machine

Fitur

  • J23 series are general open-tilting power press with simple structure ,reliable performance and easy operation .J23 can adopt rigid turn-key clutch .
  • So, it is convenient for operation and maintenance .J23 can also adopt emergency stop service to make the slider block suddenly stop on the range of 0-135 degree,and the photoelectrical protector device is optional .
  • J23-100B and J23-125 are special among the J23 series .Their main body is cast in iron .The cranked axle is settled vertically .Eccentric sleeve makes easy adjustment .And there is also pneumatic friction.Therefore ,J23-100B and J23-125 enable to work with small impact and sationarity and make slider block stop at any position .

Aplikasi

Spesifikasi

Spesifikasi
Satuan
JB23-40
JB23-63
JB23-63A
Tekanan nominal
KN
400
630
630
Gaya nominal stroke
mm
4
4
4
Stroke penggeser
mm
80
80
80
Jumlah gerakan penggeser
kali/menit
50
50
50
Tinggi set mati maksimum
mm
230
250
300
Penyesuaian ketinggian set mati
mm
45
50
50
Jarak dari pusat penggeser ke bingkai
mm
220
250
250
Dimensi meja kerja
mm
390x630
420x650
470x750
Ketebalan panel meja kerja
mm
70
70
80
Ukuran lubang pegangan
(diameter x kedalaman)
mm
50x70
50x70
50x70
Jarak kolom vertikal
mm
330
320
390
Motor utama
Model
Y112M-4
Y132S-4
Y132S-4
Kekuatan
KW
4
5.5
5.5
Sudut kemiringan maksimum tubuh
°
25
25
25
Dimensi keseluruhan (PxLxT)
mm
1600X1100X2250
1740X1100X2560
1740X1180X2560
Berat
kg
2960
3800
4300
